Magnets for sound systems
The sound system industry is always looking to improve the quality of acoustics and product performance, coming up with smaller and smaller appliances. Few people know that magnets lie at the heart of the sound system, therefore they must be given their due importance.
This is why we have developed this product line that includes magnets and magnetic assemblies.
In the past, powders and technologies were used to create magnets that provided results with scant quality and sound power, the magnets were large and heavy and it was difficult to adapt the shape of the magnets to individual requirements, giving rise to similar products that all had the same mass. Today, thanks to the new mixtures of powders and advanced manufacturing technologies and especially the possibility to control the magnetic flux, it is now possible to guarantee particular shapes and Gauss values that are especially calibrated for specific applications.
APPLICATION GROUPS
All our magnets are customised according to customer requirements or are made in close collaboration with the customer during the design phase.MAGNETIC MATERIALS FOR SOUND SYSTEMS ARE GROUPED AS FOLLOWS:
FERRITE MAGNETIC RUBBER
Magnetic flexible rubber made of plasto-ferrite, elastic, can be made in any shape. Maximum working temperature: 80°C.
Find out more
NEODYMIUM MAGNETIC RUBBER
Magnetic flexible rubber made of plasto-neodymium. No mould required. We create shapes and sizes depending on customer requirements; the same applies to magnetic properties and the rigidity of the profile. Maximum energy product (BH max): up to 8.5 MGOe, Residual induction (Br): up to 6500 Gauss. Suitable for industrial applications. Maximum working temperature: 100°C.
Find out more
NEODYMIUM
Sintered neodymium. Maximum energy product (BH max): up to 48 MGOe Residual induction (Br): up to 14800 Gauss. Ring magnets with magnetisation on the diameter from 4 up to 24 radial poles. Other possible magnetisations: axial, multi-pole axial, radial, multi-pole radial, tilted multi-pole radial. Irreversible magnetic flux loss: <3%. Possibility of making magnets with a reduced percentage of dysprosium powder. Maximum working temperature: up to 220°C.
Find out more
FERRITE
Sintered ferrite. Various types of magnetisation such as radial, axial, diametrical and Halbach. Characterised by no magnetic field around the central hole or around the exterior of the magnet. Maximum energy product (BH max): up to 4.95 MGOe Residual induction (Br): up to 4.6 kGs. Maximum working temperature: up to 300°C.
Find out more
SAMARIUM-COBALT
Sintered samarium-cobalt magnet with a high magnetic flux rate, very similar to neodymium. Suitable for high temperatures: from 200°C up to 350°C.
Find out more
PLASTO-MAGNETS
Magnets made by injection moulding of plastic materials and magnetic components made of neodymium or ferrite. Plasto-magnets can reach very high magnetic qualities. Residual induction (Br): up to 6 kGs. Maximum energy product (BH max): up to 6.2 MGOe Intrinsic coercive force (Hcj): up to 11.5 kOe. Maximum working temperature: up to 120°C.
Find out more
ALNICO
The magnetic field of alnico magnets is very stable, with very low losses at high temperatures and excellent resistance to corrosion. Maximum working temperature: 500°C
Find out more
DOWNLOAD TECHNICAL SHEET
Do not hesitate to contact us for further information
