Magnets for fastening systems

Magnets for fastening systems are grouped into two product lines: standard and special.

The "CALAMITA" line includes standard shapes and coatings. The SPECIALE (special) line includes every magnet made according to specific customer requirements and directives.

Magnets for fastening systems have been created to meet the need of the industry for alternative solutions compared to securing items with nails, screws or adhesives and to ease product removal. Modern fastening systems require clearances reduced to a minimum, strong and powerful fastening points, attention to design and detail. Thanks to magnetic fastening systems, it is no longer necessary to use screws and screwdrivers because a magnet fixes everything. Magnet specifications are carefully researched for every specific customer application to guarantee the desired hold, and a quality fix that will remain constant through time.

The main fields of application vary from securing panels, sheets, signs and shelves installed both indoors and outdoors, creating a fastening system that has a modern and refined design, right through to fastening systems for beacons, rear light kits, lighting systems, signage, magnetic locking systems for formwork, fastening systems for magnetic layers, food industry valves and car accessories.

All our magnets are customised according to customer requirements or are made in close collaboration with the customer during the design phase.
MAGNETIC MATERIALS FOR FASTENING SYSTEMS ARE GROUPED AS FOLLOWS:
FERRITE MAGNETIC RUBBER
Magnetic flexible rubber made of plasto-ferrite, an elastic product that can be made in any shape. Maximum working temperature: 80°C.

Find out more
NEODYMIUM MAGNETIC RUBBER
Magnetic flexible rubber made of plasto-neodymium. No mould required. We create shapes and sizes depending on customer requirements; the same applies to magnetic properties and the rigidity of the profile. Maximum energy product (BH max): up to 8.5 MGOe. Residual induction (Br): up to 6500 Gauss. Suitable for industrial applications. Maximum working temperature: 100°C.

Find out more
NEODYMIUM
Sintered neodymium guarantees a high force of attraction and holding force. Several coating types available. Ideal for fastening heavy materials. Maximum working temperature: 200°C.

Find out more
PLASTO-MAGNETS
Magnets made by injection moulding of plastic materials and magnetic components made of neodymium or ferrite. Plasto-magnets can reach very high magnetic qualities. Residual induction (Br): up to 6 kGs. Maximum energy product (BH max): up to 6.2 MGOe. Intrinsic coercive force (Hcj): up to 11.5 kOe. Maximum working temperature: up to 120°C.

Find out more
SAMARIUM-COBALT
Sintered samarium-cobalt magnet with a high magnetic flux rate, very similar to neodymium. Suitable for high temperatures: from 200°C up to 350°C.

Find out more
FERRITE
Sintered ferrite can be manufactured into different types of shapes: segments, cylinders, rings, blocks and many others thanks to the use of moulds. Maximum working temperature: 300°C.

Find out more
ALNICO
The magnetic field of alnico magnets is very stable, with very low losses at high temperatures and excellent resistance to corrosion. Maximum working temperature: 500°C.

Scopri di più
MAGNET
Magnets can be supplied with a rubber, resin, steel or plastic coating. Rear features a pin or hole for quick and easy assembly.
ELECTROMAGNET
An electromagnet consists in a ferrous-magnetic nucleus with a coil wound around it. It generates a magnetic field when activated by an electric current. When the current flows through the electromagnet, the magnetic nucleus is activated guaranteeing closure.
 DOWNLOAD TECHNICAL SHEET
 DOWNLOAD "CALAMITA" LINE TECHNICAL SHEET
 DOWNLOAD FOLDER "CALAMITA"

Do not hesitate to contact us for further information

Send a message
